Laboratory for Structural Engineering

non-contact measuring technology - measuring arm

Mercury 3D Dehnungsverteilung

Digital 3D image correlation measurement system

Measuring arm
_©_{hexagonmetrology.at}

Absolute Arm

Digital measuring arm with ruby measuring tip and laser measuring unit

Conventional measurement technology

_{© TU Graz/LKI}	4 pcs. HBM QuantumX 840A 2 pcs. HBM QuantumX 840B 8 channel universal measuring amplifier
_{© TU Graz/LKI}	1 pcs. HBM QuantumX 1615B 16 channel strain gauge bridge amplifier
_{© TU Graz/LKI}	1 pcs. HBM QuantumX 879B Analog/Digital I/O Modul
_{© TU Graz/LKI}	1 pcs. HBM DMC Plus (large size) 14 DV55 slots (28 channels 4.8kHz carrier frequency)
_{© TU Graz/LKI}	3 pcs. HBM DMC Plus (small version) 5 plug-in units each (DV55, DV35, DV30, DV10)
_{© TU Graz/LKI}	1 pcs. HBM DMD20A 1 channel measuring amplifier for measuring strain gauge circuits in full or half bridge. Also serves for calibration by means of a calibration device.
_{© TU Graz/LKI}	1 pcs. HBM Calibration Device K3607 Serves to simulate defined output signals of 350Ohm strain gauge full bridge transducers 30 calibration signals between 0.05mV/V and 10mV/V

Force measurement

_{© TU Graz/LKI}	Compression load cell 2 pcs. HBM C2 2t 4 pcs. HBM C2 100kN Accessories: Device for tensile load
_{© TU Graz/LKI}	Tension and compression load cell 1 pc. HBM U2A 1kN 1 pc. HBM U2B 2kN 1 pc. HBM U2B 5kN 1 pc. HBM U2B 10kN 1 pc. HBM U2B 20kN 1 pc. HBM U2B 50kN 4 pcs. HBM U2B 5t 1 pc. HBM U2B 100kN
_{© TU Graz/LKI}	Compression load cell 1 pc. HBM Z12 200kN
_{© TU Graz/LKI}	Load cell 7 pcs. HBM Z6 5kg

Displacement measurement

Displacement measurement _{© TU Graz/LKI}	Inductive displacement transducer 16 pcs. HBM W5TK (measuring range: ±5mm) 7 pcs. HBM W10TK (measuring range: ±10mm) 3 pcs. HBM W20TK (measuring range: ±20mm)
_{© TU Graz/LKI}	Inductive displacement transducer with probe tip 4 pcs. HBM WA2 (measuring range: 2mm) 4 pcs. HBM WA10 (measuring range: 10mm) 6 pcs. HBM WA20 (measuring range: 20mm) 1 pc. HBM WA100 (measuring range: 100mm)
_{© TU Graz/LKI}	Inductive displacement transducer with plunger 3 pcs. HBM W50 (measuring range: ±50mm) 3 pcs. HBM WA50 (measuring range: 50mm) 1 pc. HBM WA100 (measuring range: 100mm) 4 pcs. HBM WA200 (measuring range: 200mm)
_{© TU Graz/LKI}	Extensometer with a measuring range of 0-1000mm analogue output (1kOhm) 1 pc. ASM rope extensometer

Strain measurement

_{© TU Graz/LKI}	27 pcs. HBM DD1 strain transducer on strain gauge basis with accessories (blades, tips, measuring bases)
_{© HBM}	Strain gauge applications

Vibration measurement

_{© TU Graz/LKI}

3 pcs. HBM SMU 31
Vibration meter
Measurement of vibration displacement, vibration velocity and vibration acceleration

_{© TU Graz/LKI}

Accelerometer
2 pc. HBM B12-200

Pressure measurement

Pressure measurement

Pressure transducer
1 pc. HBM P3MBR 5bar
1 pc. HBM P3MBP 1000bar
1 pc. HBM P6A 200bar
1 pc. HBM P6A 500bar
